EVGA GeForce GTX 690 review

Nvidia's seriously beautiful dual-GPU card

TODO alt text

Nvidia has done a great job engineering the GeForce GTX 690.

Squeezing two graphics cards into one is something it is now used to doing of course, but the fact it has managed it without sacrificing too much straight line speed is impressive.

The twin pairing of two GTX 680s in SLI is still the top performance configuration, if you've got the ready cash, the airflow through your chassis and one mother of a power supply. But the Nvidia GeForce GTX 690 is incredibly close in terms of raw frame rates to that setup.

You're losing out on one or two frames per second on average at most in opting for the single card versus the SLI setup.

That just demonstrates how well the GPU boost technology pushes on from that initially low 915MHz base clock.

EVGA GeForce GTX 690
Serious cooling for a serious card

It's also possible to push the performance even further should you want to really stress that £830/$1,000 purchase of yours. We managed another, stable, 110MHz offset, which translated to gaming performance of around 1,155MHz.

Still, that overclock only gave us another couple of frames per second across the board, but that's enough to push it ahead of the GTX 680 SLI configuration.

The problem for the Nvidia GeForce GTX 690 though comes in the shape of the recently released Nvidia GeForce GTX 670 cards.

Obviously on their own they represent no real challenge to the majesty of the GTX 690, but jam a pair of them into a system and for nigh-on £200/$200 less you've got a setup that performs almost as well.

As the GTX 690 is only just short of the GTX 680 in SLI, so is the GTX 670 SLI setup.

A pair of Nvidia GTX 670s though still needs a hefty PSU with the requisite PCIe power connectors to make good of the configuration.

Under full load the Nvidia GeForce GTX 690 draws a not-inconsiderable 416w, but that is still a lot less thirsty than either SLI configurations of the GTX 670 or GTX 680, at 430W and 480W respectively.

Tech Specs

Product TypeGraphic Card
Chipset ManufacturerNVIDIA
Chipset ModelGTX 690
Chipset LineGeForce
Chipset SeriesGTX 600
Maximum Resolution2560 x 1600
Brand NameEVGA
Standard Memory4 GB
Host InterfacePCI Express 3.0 x16
HDCP SupportedYes
Bus Width512 bit
Multi-GPU TechnologySLI
RAMDAC Speed400 MHz
Analog SignalYes
Digital SignalYes
Dual Link DVI SupportedYes
Number of DisplayPort Outputs1
Number of DVI Outputs3
Height111.2 mm
Cooler TypeFan Cooler
Memory TechnologyGDDR5 SDRAM
Form FactorPlug-in Card
Length279.4 mm
ManufacturerEVGA Corporation
Memory Speed6008 MHz
Product NameGeForce GTX 690 Signature
Manufacturer Part Number04G-P4-2692-KR
Manufacturer Website Addresshttp://www.evga.com
Marketing Information

The EVGA GeForce GTX 690 is NVIDIA's fastest graphics card... ever. It combines the groundbreaking new GeForce architecture with raw dual-GPU power to provide truly game-changing performance. Get superior gaming innovation that is meticulously designed - inside and out - for the fastest, smoothest, richest gaming experience.

Package Contents
  • GeForce GTX 690 Signature
  • Disc
  • 1 x DVI to VGA Adapter (For DVI-I)
  • 1 x DVI to HDMI Adapter
  • 2 x Dual 6-pin to 8-pin Adapter
  • Accessory Pack
  • T-Shirt
  • Mousepad
  • User Guide
Limited Warranty3 Year
Weight (Approximate)1.81 kg
API SupportedDirectX 11.0, DirectCompute, OpenGL 4.2, OpenCL
